Optical Add Drop Multiplexer Module Fiber Optic 4 Channel Oadm Mux Demux

Brand Name : Sourcelight or OEM

Model Number : 4 Channel Oadm Mux Demux

Certification : ISO9000 SGS CE FCC

Place of Origin : Shenzhen,China

MOQ : 1pcs

Price : Get Latest Price

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 1000pcs/Month

Delivery Time : Shipped in 3~5 days after PO confirmed

Packaging Details : 1pcs in a foam with paper box

Product Name : 4 Channel Oadm Mux Demux

Channel Number : 4 Channels

Wavelength : ITU Grid

Fiber Type : smf G652

Connector : LC/SC/FC/ST (PC Or APC)

ABS Box : L140 X W115 X 18

Contact Now

Fiber Optic 4 Channel Oadm Mux Demux , Optical Add Drop Multiplexer Module



Sourcelight’s Optical add/drop Multiplexer are available on ITU channel spacing of 100GHz ,20nm they are based on thin film filtertechnology and flexible integration of taps and detectors for acomplete dense wavelength division multiplexing solution.It can be used for CWDM and DWDM optical network.



Key Feature

  • ITU channel spcaing
  • Low insertion loss
  • Wide pass band
  • High Channel Isolation
  • High Stability and reliability
  • Epoxy-free on Optical Path



Application

  • Channel Add/Drop
  • DWDM Network
  • Wavelength Routing
  • Fiber Optical amplifier
  • CATV fiberoptic System



Specification

Parameter 4 Channel 8 Channel
Channel Wavelength (nm) ITU Grid
Channel Spacing (GHz) 100 CWDM
Center wavelength Accuracy (nm) ±0.11 ±6.5
Channel Passband (@-0.5dB bandwidth (nm) >0.3 ＞14
Insertion Loss (dB) In—Drop@drop> 2.0 3.2
Add---Out@add 2.0 3.2
In---out@other 2.5 5.0
Add/Drop Channel Ripple (dB) <0.3
Isolation @Add/Drop Channel Adjacent >25 >30
Non-adjacent >45 >45
Inertion Loss Temperature Sensitivity (dB/℃) <0.005
Wavelength Temperature Shifting (nm/℃) <0.002
Polarization Dependent Loss (dB) <0.1
Polarization Mode Dispersion (ps) <0.1
Directivity (dB) (Input to add, Output to drop, add to drop >50
Return Loss (dB) >45
Maximum Power Handling (mW) 500
Opterating Temperature (℃) -10~+75
Storage Temperature (℃) -40~+85
Package dimension (mm) ABS Box L100 x W80x H10.5 L140 x W115 x 18
1U Chassis 440(W)× 44(H)×340(D)



Optical Add Drop Multiplexer Module Fiber Optic 4 Channel Oadm Mux Demux
